BEE-12 - Passive portable speaker

BEE-12 - Passive portable speaker

BEE-12 is a passive universal FOH and stage monitoring speaker fitted with a low-distortion 12” coaxial driver with 3” low-frequency voice coil and 2,8” voice coil. It is connected using the industry-standard Speakon connector, allowing for simple integration into any sound reinforcement setup.

Product description:

Passive portable speaker

Main features:

  • 500W nominal power
  • 12”, coaxial with 3” voice coil
  • 135 dB Max SPL
  • M10 safety point; 35 mm pole socket; 4x M10 flying points


Read more about application:

All new MAG Audio BEE-Series: BEE-12, BEE-12A, BEE-15, BEE-15A

Main
Type Passive portable speaker
Acoustical & Electrical data
Frequency response (-10dB) 60 - 18000 Hz
Max SPL 1 135 dB
Sensitivity (1W/1m) 96 dB
LF Driver 12”, coaxial 3" VC
Nominal Coverage Angle (Horizontal × Vertical) 80 x 80 deg
Impedance 8 Ohm
Nominal power 2 500 W
Connections and physical data
Connectors 2x NeutrikSpeakon
Dimensions (W x H x D) 370 x 350 x 550 mm / 14,57” x 13,79” x 21,65”
Net weight 19,7 kg
Mounting 4x M10 flying points, 35mm pole socket, M10 safety point
Enclosure material Plywood; wear resistant paint
Speaker protection Steel grill, acoustically transparent backing

1 pink noise, filtered according to AES 2 - 2012, crest factor 12 dB

2 based on transducer power measured according to AES 2 - 2012
