BEE-15 - Passive portable speaker
BEE-15 is a passive universal FOH and stage monitoring speaker fitted with a low-distortion 15” coaxial driver with 3” low-frequency voice coil and 2,8” voice coil. It is connected using the industry-standard Speakon connector, allowing for simple integration into any sound reinforcement setup.
Product description:
Passive portable speaker
Main features:
- 500W nominal power
- 15”, coaxial with 3” voice coil
- 136 dB Max SPL
- M10 safety point; 35 mm pole socket; 4x M10 flying points
Read more about application:
All new MAG Audio BEE-Series: BEE-12, BEE-12A, BEE-15, BEE-15A
| Main | |
|---|---|
| Type | Passive portable speaker |
| Acoustical & Electrical data | |
| Frequency response (-10dB) | 50 - 18000 Hz |
| Max SPL 1 | 136 dB |
| Sensitivity (1W/1m) | 97 dB |
| LF Driver | 15”, coaxial 3" VC |
| Nominal Coverage Angle (Horizontal × Vertical) | 80 x 80 deg |
| Impedance | 8 Ohm |
| Nominal power 2 | 500 W |
| Connectors | 2 x NeutrikSpeakon |
| Connections and physical data | |
| Dimensions (W x H x D) | 440 x 390 x 680 mm / 17,32” x 15,34” x 26,77” |
| Net weight | 23,45 kg |
| Mounting | 4 x M10 flying points, 35mm pole socket, M10 safety point |
| Enclosure material | Plywood; wear resistant paint |
| Speaker protection | Steel grill, acoustically transparent backing |
1 pink noise, filtered according to AES 2 - 2012, crest factor 12 dB
2 based on transducer power measured according to AES 2 - 2012
