AIR-C4 - Іnstallation speaker
Installation solutions
High-quality installation-ready speakers
Indoor & outdoor use
Compact enclosures designed to fit into any interior
Fitting everywhere
Including versatile mounting brackets
Realibility
Long-life own designed components
The most compact system in the series, AIR-C4 has received the 4” woofer and an HF driver on a rotatable horn. It is compatible with horizontal and vertical adjustable mountings and is available in both Hi-Z and Lo-Z versions.
Product description:
Іnstallation speaker
Main features:
• 50 W nominal power
• 4”, 1" VC LF driver
• 117 dB Max SPL
• VESA 50x50, Safety mounting point
Read more about application:
MAG Audio AIR-C Series: install, mounting & safety solutions (VIDEO)
MAG Audio AIR-C — a new benchmark for installation acoustics
| Main | |
|---|---|
| Type | Passive installation speaker |
| Acoustical & Electrical data | |
| Frequency response (-10dB) | 90 - 20000 Hz |
| Max SPL 1 | 117 dB |
| Sensitivity (1W/1m) | 88 dB |
| LF Driver | 4”, 1" VC |
| HF Driver | 1” carbon fiber diaphragm, 1” VC, ND magnet |
| Nominal Coverage Angle (Horizontal × Vertical) | 100° x 70°, rotatable horn |
| Impedance | 16 Ohm |
| Nominal power 2 | 50 W |
| Connections and physical data | |
| Connectors | Phoenix |
| Dimensions (W x H x D) | 146 x 260 x 154 мм; 5,75” x 10,24” x 6,1” |
| Net weight | 2,7 kg; 6 lbs |
| Shipping weight | 3,5 kg; 7,7 lbs |
| Mounting | VESA 50 x 50; Safety mounting point |
| Weather protection | IP54 rated |
| Enclosure material | Polycomp©, wear-resistant paint |
| Speaker protection | Steel grill, acoustically transparent backing |
1 pink noise, filtered according to AES 2 - 2012, crest factor 12 dB
2 based on transducer power measured according to AES 2 - 2012
