NX 12A - Powered full-range speaker
Versatile, powerful, and compact NX 12A powered speaker features low distortion 12” neodymium woofer and a 1,5” neodymium HF driver. Due to compact dimensions and considerable power output, NX 12A is a match for rental, touring, or complete sound reinforcement solutions. Innovative D-class Powersoft built-in amplifier offers superior energy-efficient operation and perfect control over sound properties.
Product description:
Powered full-range speaker
Main features:
• 900 + 500 W nominal power
• 12” woofer with 3” voice coil
• 1,5” HF driver with 2,8” voice coil
• 134 dB Max SPL
• Pole mount adapter, M10 mounting points
NX 12 example sets:
Read more about the application:
MAG NX 12A at Malevich Summer Terrace
NX series from MAG Audio for the Ice Rink in Kramatorsk (Ukraine)
NX series Loudspeakers Deployed in the Netherlands’ 100-year-old Theater Podium Zuidhaege
NX series and Green Technologies: the College of Future Terra Emmen in the Netherlands
| Main | |
|---|---|
| Type | Powered full-range speaker |
| Acoustical & Electrical data | |
| Frequency response (-10dB) | 50 - 19000 Hz |
| Max SPL (calculated) | 135 dB |
| LF Driver | 12”, 3" VC |
| HF Driver | 1,5”, 2,8" VC |
| Nominal Coverage Angle (Horizontal × Vertical) | 80 x 70 deg |
| Amplifier power | 900+500 W |
| Amplifier | Class D, fan cooling, DSP with phase-linear FIR |
| Input sensitivity | 0 dBV (1 V RMS) |
| Connectors | XLR input, XLR output, Powercon mains |
| Connections and physical data | |
| Dimensions (W x H x D) | 379 x 655 x 367 mm |
| Net weight | 25 kg |
| Shipping weight | 27 kg |
| Mounting | 10 x M10 mounting points, 35 mm pole socket, Carrying handles, Plastic feet |
| Enclosure material | Plywood; wear-resistant paint |
| Speaker protection | Steel grill, acoustically transparent backing |
