AIR-152 IP - Weather-resistant speaker
Installation solutions
High-quality installation-ready speakers
Indoor & outdoor use
Compact enclosures designed to fit into any interior
Fitting everywhere
Including versatile mounting brackets
Realibility
Long-life own designed components
Powerful installation-dedicated system with 15'' coaxial woofer. Compact and carefully optimized enclosures have been designed to make the model fit into any interior, achieving most performance per the space occupied.
Product description:
Weather-resistant speaker
Main features:
• 600 W nominal power
• 15” coaxial driver
• 134 dB Max SPL
• VESA 100x100, M10 mounting points
Read more about application:
Panorama M-Lounge Bar in Bukovel Upgrades with AIR series
Harmony of white AIR series and the interior of sea restaurant
AIR series in the Palace of Culture in Oleksandriya city
| Main | |
|---|---|
| Type | Weather-resistant speaker |
| Acoustical & Electrical data | |
| Frequency response (-10dB) | 50 - 18000 Hz |
| Max SPL 1 | 134 dB |
| Sensitivity (1W/1m) | 97 dB |
| LF Driver | 15" coaxial |
| Nominal Coverage Angle (Horizontal × Vertical) | 80 x 80 deg |
| Impedance | 4 / 8 Оhm |
| Nominal power 2 | 600 W |
| Connections and physical data | |
| Connectors | Phoenix |
| Dimensions (W x H x D) | 530 x 619 x 348 mm |
| Net weight | 25,5 kg |
| Shipping weight | 27,5 kg |
| Mounting | VESA 100 x 100; 4 x M10 Mounting points; M10 safety point |
| Weather protection | IP 54 weather-protection |
| Enclosure material | Plywood; wear-resistant paint |
| Speaker protection | Steel grill, acoustically transparent backing |
1 pink noise, filtered according to AES 2 - 2012, crest factor 9 dB
2 based on transducer power measured according to AES 2 - 2012
