AIR-82 IP - Weather-resistant speaker

AIR-82 IP - Weather-resistant speaker
Installation solutions
High-quality installation-ready speakers
Indoor & outdoor use
Compact enclosures designed to fit into any interior
Fitting everywhere
Including versatile mounting brackets
Realibility
Long-life own designed components

Weather-resistant speaker, AIR-82 IP comes in extremely compact size, featuring 8” coaxial woofer. The model has numerous mounting options, providing usability for each and every project.

Product description:

Weather-resistant speaker

Main features:

• 250 W nominal power

• 8” coaxial driver

• 127 dB Max SPL

• VESA 75x75, M10 mounting points


Read more about application:

Panorama M-Lounge Bar in Bukovel Upgrades with AIR series

Harmony of white AIR series and the interior of sea restaurant

AIR series in Blur Coffee

AIR series in the Palace of Culture in Oleksandriya city

Sound of Victory: AIR series at “Kolos” Stadium

Main
Type Weather-resistant speaker
Acoustical & Electrical data
Frequency response (-10dB) 80 - 18000 Hz
Max SPL 1 127 dB
Sensitivity (1W/1m) 94 dB
LF Driver 8" coaxial
Nominal Coverage Angle (Horizontal × Vertical) 90 x 90 deg
Impedance 4 / 8 / 16 Ohm
Nominal power 2 250 W
Connections and physical data
Connectors Barrier strip / Gland nut cover plate
Dimensions (WxHxD) 354x383x254 mm
Net weight 9,5 kg
Shipping weight 10,5 kg
Mounting VESA 75x75; 2x M10 Mounting points; M10 safety point
Weather-protection IP 54 weather-protection
Enclosure material Plywood; wear-resistant paint
Speaker protection Steel grill, acoustically transparent backing

1 pink noise, filtered according to AES 2 - 2012, crest factor 9 dB

2 based on transducer power measured according to AES 2 - 2012
